The Medium Speed Trapezium Mill (MTW) is a popular grinding machine used for processing non-flammable and non-explosive mineral materials with a hardness below 9.3 on the Mohs scale and humidity below 6%. It is widely used in industries such as mining, construction, chemical engineering, and metallurgy.
Key Features of MTW Medium Speed Trapezium Mill:
1. Advanced Grinding Technology
– Uses a curved blade shovel to improve grinding efficiency.
– Equipped with an inner oil lubrication system for smooth operation.
2. High Efficiency & Low Energy Consumption
– Optimized grinding roller and ring design for better performance.
– Reduces power consumption compared to traditional mills.
3. Durable & Reliable Structure
– Reinforced steel frame for long-term stability.
– Wear-resistant materials extend the machine’s lifespan.
4. Environmentally Friendly
– Low noise and dust emissions.
– Equipped with a pulse dust collector to meet environmental standards.
5. Easy Maintenance & Automation
– Hydraulic system for easy roller adjustment.
– PLC control system allows for automated operation.
Technical Specifications (MTW Series)
| Model | MTW110 | MTW138 | MTW175 | MTW215 |
|——-|——–|——–|——–|——–|
| Max Feed Size (mm) | ≤30 | ≤30 | ≤35 | ≤40 |
| Finished Particle Size (μm) | 1.6-0.045 | 1.6-0.045 | 1.6-0.045 | 1.6-0.038 |
| Capacity (t/h) | 3-15 | 6-25 | 15-50 | 20-100 |
| Motor Power (kW) | 185 | 280 | 400 | 630 |
.jpg)
Applications
– Grinding limestone, calcite, dolomite, barite, talc, gypsum, bentonite, etc.
– Used in cement plants, power plants, and mining operations.
Advantages Over Traditional Mills
✔ Higher production capacity
✔ Lower maintenance costs
✔ Better particle size distribution
